Dana 25-10140081 CV Joint Repair Kit

Dana 25-10140081 CV Joint Repair Kit

The Dana 25-10140081 repair kit is a high-quality CV (constant velocity) joint replacement assembly designed for front driveshafts. It is engineered to match factory specifications (OEM) and intended to restore the smooth power transfer across steering angles that the original CV joint once provided.

• Complete CV Joint Assembly: The kit includes a replacement CV joint unit, along with necessary hardware for installation (snap ring, boot clamp, grease, etc.).
• Spline Count & Dimensions: This is a 25-spline joint.
• Bolt Pattern / Mount Details:
  • Bolt circle diameter: ~ 3.395 in
  • Bolt diameter: ~ 0.345 in
  • Thread spec: M8 × 1.25 mm
  • Housing outer diameter: ~ 3.93 in
  • Housing thickness: ~ 1.18 in
  • Number of mounting holes: 6
  • Spline length: ~ 0.96 in
• Materials & Build: Precision steel construction to maintain strength and durability under torque and rotational stresses.
• Grease / Sealing: The kit includes lubricant (grease) and seal components to help ensure longevity by protecting internal joint surfaces from contaminants and wear.
