Euroricambi 24170174 Side Gear – 18 Teeth / 41 Splines (Interchange for Dana / Spicer 110527)
The Euroricambi 24170174 Side Gear is a premium aftermarket differential side gear manufactured as a direct interchange for Dana / Spicer OEM 110527. Designed for heavy-duty commercial truck and off-highway axle applications, this precision-engineered gear features 18 external gear teeth and 41 internal axle splines, providing reliable torque transfer and long service life in demanding operating environments.
Manufactured in Italy by Euroricambi, one of the world’s leading suppliers of replacement drivetrain components for commercial vehicles, the 24170174 is produced using high-quality alloy steel, precision machining, and advanced heat-treatment processes to meet or exceed OEM performance standards. The gear is designed for use in Dana Spicer single- and double-reduction drive axles commonly found in heavy-duty trucks, vocational vehicles, construction equipment, mining machinery, and other severe-service applications.
As the primary axle shaft gear within the differential assembly, the side gear transfers torque from the differential case to the axle shaft while allowing the differential pinion (spider) gears to compensate for differences in wheel speed during turning. Proper gear geometry and spline accuracy are essential for smooth operation, reduced wear, and maximum drivetrain reliability.
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | Euroricambi |
| Part Number | 24170174 |
| OEM Interchange | Dana / Spicer 110527 |
| Component Type | Differential Side Gear |
| Gear Teeth | 18 Teeth |
| Internal Splines | 41 Splines |
| Application | Dana / Spicer Drive Axles |
| Material | Heat-treated alloy steel |
| Manufacturing | Precision machined and hardened |
| Unit Weight | 5.34 lb |
| Package Quantity | 1 |
| Country of Manufacture | Italy |
Cross References:
- Dana/Spicer 110527
- General Motors 15513213
- AM Gears 66314
- Eurotec 24000167
- PAI 94470, 9447, EE94470
- Freightliner ETN110527
- Navistar ETN0110527, DS110527
- Mack 2719-110527
- OE Aftermarket 6843932
The Euroricambi 24170174 is suitable for numerous Dana / Spicer single- and double-reduction axle models, including:
Dana / Spicer Single Reduction Axles
- 18100-1, 18120-1
- 21065D, 21065S
- 21121
- 22065D, 22065S
- 22121
- 381 RS
- 402 RS
Dana / Spicer Double Reduction Axles
- 18200-1, 18220-1, 18300-1, 18320-1
- 21065P, 21065T
- 21221, 21321
- 22065P, 22065T
- 22221, 22321
- 381 RP, 381 RT
- 402 RP, 402 RT
Forward Drive Axles
- 381(P) DP, 381(P) DS, 381(P) DT
- 402(P) DP, 402(P) DS, 402(P) DT
